| BASIC INFO |
| Model No. |
UNIWA
NR5502 |
| Product Name |
Handheld
5G Android Smart Scanning PDA |
| Operation system |
Android
13 |
| Dimension |
160.5*70.6*14.9mm |
| Net weight |
256g
(include battery) |
| Color |
Black,
white |
| Languages |
Multi-languages |
| HARDWARE |
| Screen |
5.5
inch Incell IPS capacitive touch screen, 1440*720px, brightness: 500cd/m2 |
| Processor |
Mediatek
MT6833 (2*A76+6*A55) octa core 2.2GHz;
GPU: Mali-G57 MC2 |
| RAM |
6GB
RAM |
| ROM |
128GB
ROM, support TF extension up to 256GB maximally |
| Camera |
Double
cameras: 2MP front, 13MP anti-shake PDAF rear camera with flashligt |
| Speaker |
1W
waterproof speaker |
| Battery |
Removable
3.85V/4200mAh li-polymer battery |
| Sensors |
Gravity
sensor, light sensor, proximity sensor, Magnetic field sensor, gyro sensor |
| Keys |
Power Button*1、Volume
+/-, Scanning Button*2 |
| NETWORK
& CONNECTIVITY |
| Network Bands |
2G:
GSM 850/900/1800/1900MHz |
| 3G: WCDMA 850/900/1900/2100MHz; CDMA BC0 |
| 4G: FDD-LTE B1/2/3/5/7/8/9/19; TDD-LTE:
B34/39/38/40/41/42/43/48 |
| 5G: NR N1/N3/N28/N41/N77/N78/N79 |
| WiFi |
IEEE
802.11 ac/a/b/g/n/d/e/h/i/j/k/r/v protocol, support 2.4GHz/5GHz dual band
wifi |
| BT |
V5.0
BLE, transmission distance 5~10 meters |
| GNSS |
Support
GPS/A-GPS/GLONASS/Beidou/Galileo |
| I/O
INTERFACES |
| SIM Card slot |
*2
( Nano+ Nano or Nano+micro SD) |
| USB Type-C Port |
*1,
support OTG |
| Charging Base Contacts |
*2 |
| RELIABILITY |
| Water Resistant Grade |
IP66 |
| Anti-Drop Grade |
1.5
meters |
| Operating Temperature |
-20℃
- 55℃ |
| Storage Temperature |
-40℃
- 70℃ |
| OPTIONAL
FUNCTIONS |
| 2D Scanning Module |
Optional
(Honeywell N6703 N5703 etc.) |
| NFC |
Optional |
| STANDARD
ACCESSORIES |
| Power Adaptor (5V/3A) |
*1 |
| Battery |
*1 |
| USB cable |
*1 |
| Lanyard |
*1 |
| User Manual |
*1 |
